Immersion circulator MX
PolyScience
Product number:
6522208
Manufacturer:
PolyScience
Packaging information:
Description
Immersion circulator for all kinds of water baths. It clamps securely to both straight and curved tank walls. The patented, closed housing protects the user and the heating element.
- Minimum working depth 7,5inch/19 cm
- Large LCD-display
- Display resolution 0,1 °C
- Displays actual and set point temperature simultaneously
- Integrated pump and heater protection
- Integrated over-temperature protection
- Low liquid level protection
- Included clamp for straight and curved tank walls
Properties
| Depth: | 97 mm |
|---|---|
| Dimensions (WxDxH): | 109 x 97 x 358 mm |
| Heating capacity: | 1100 W |
| Height: | 358 mm |
| IP code: | IP 31 |
| Manufacturer Article Number: | MX-CA11B |
| Max. delivery pressure: | 0.16 bar |
| Max. flow rate: | 13.5 l/min |
| Max. temperature: | 135 °C |
| Max. voltage: | 120 V |
| Min. temperature: | +10 °C |
| Power supply: | 120 V, 60 Hz |
| Power supply frequency: | 60 Hz |
| Programmable: | No |
| Temperature: | RT+10 ... 135 °C |
| Temperature addition: | RT |
| Temperature stability: | ±0,07 °C |
| Type: | MX |
| Type of auxiliary energy: | Mains connection |
| Type of display: | LCD |
| Width: | 109 mm |
| With timer: | No |
