Laboratory freezers LF, with explosion-proofed interior
Product number:
6270298
Manufacturer:
Arctiko A/S
Packaging information:
Weight:
162 kg
Description
Laboratory freezers for the storage of explosive and highly flammable substances. With explosion-proof interior and approved to EN 60079-15 category 3, zone 2, CE EX 11-/3 G.
- White steel exterior, stainless steel interior
- Automatic door closing
- Air forced cooling, adjustable shelves, castors, key lock on door
- Micro processor controller with digital display
- Approx. 72 hours battery back up for alarms, loggings and temperature display in case of power cut
- Prepared for GSM alarm
- Prepared for connection of 2 additional probes
- Auto cycle in case of probe failure
- Ambient temperature display
- Direct download of logged data on USB memory stick, direct upload of new software via USB memory stick
- 3-level password protected
- Battery level indication
- Display text available in different languages
- Temperature graph, integrated data logger
- RS485/RS232 interface
- Integrated memory for 30 years
- Visual and acoustic alarm
- Adjustable high/low temperature alarm
- Alarms: Power failure, probe failure, instrument failure, open door
- Contact for remote alarm, shows all alarms
- 5 year warranty on the compressor
Properties
| Colour: | White |
|---|---|
| Depth int.: | 685 mm |
| Energy consumption (24h): | 9.8 kWh |
| Ext. depth: | 860 mm |
| Ext. height: | 1997 mm |
| Ext. width: | 720 mm |
| External dimensions (WxDxH): | 720 x 860 x 1,997 mm |
| Height int.: | 1505 mm |
| Int. width: | 600 mm |
| Internal dimensions (WxDxH): | 600 x 685 x 1,505 mm |
| Manufacturer Article Number: | 1400009 |
| Max. temperature: | -10 °C |
| Min. temperature: | -30 °C |
| Min. voltage: | 230 V |
| No. of chambers: | 1 |
| No. of doors: | 1 |
| No. of shelves: | 3 |
| Nominal capacity: | 618 l |
| Temperature: | -30 ... -10 °C |
| Type: | LF 700 ATEX |
| Type of auxiliary energy: | Mains connection |
| Weight: | 133 kg |
