Multiparameter meter MultiLine® 3620 IDS Set WL

Professional pH and redox meter for mobile measurements. The pH/Cond 3320 has a robust, waterproof housing (IP67) and is equipped with a memory as well as a data logger with an adjustable interval between 1 s and 60 min. All entries contain GLP-supporting data, like the date, time and ID number. The modern, waterproof USB interface is used for easy and quick data transfers. Applications: Process chemistry, Life Science, food and beverage industry, pharmaceutical industry (measurement of pH and conductivity according to pharmacopeia).Two inputs for the simultaneous measurement of pH/mV/ISE/redox potentail and conductivityBacklit graphic display for the parallel display of the measured valuesPerfect for monitoring process applicationsWaterproof USB interfaceScope of supply: Meter in transport case with SenTix® 41, TetraCon® 325, buffer solution STP 4 and STP 7, conductivity standard 0.01 mol/l KCl, manual, stand, beaker, CD-ROM, driver software for USB, battaries, cableSpecificationsMeasuring range / ResolutionpH:-2.000 … 19.999 ± 0.005 pHmV:-2500 ... +2500 ± 1 mVISE (mg/l, µmol/l, mg/kg, ppm, %):0.000 … 999999Conductivity:0.000 µS/cm ... 1000 mS/cmSalinity:0.0 ... 70.0TDS:0 mg ... 199.9 g/lTemp.:-5.0 … 105.0 °C ± 0.1 °CMemory:Manually 200/5000 automaticallyPower supply:4 x 1.5 V AA or 4 x 1.2 V NiMH batteryIP code:IP 67

The device SD50 is a robust benchtop meter for measuring pH / mV, ion concentration, and temperature.Large 7" touch screen with intuitive user interfaceElectrode arm EasyPlace™ places the sensor preciselyIntelligent Sensor Management (ISM®) ensures the correct use of the connected sensorAutomatic data transfer to PC or printerCalibration with up to 5 calibration pointsAdditional splash protection thanks to removable coverGLP compliantScope of supply: pH / ion meter, electrode arm EasyPlace™, protective cover, power supply, get-started-guidepH range:-2.000 ... 20.000Accuracy:±0.002Resolution:0.1 / 0.01 / 0.001Calibration points:1 ... 5mV range:2000.0 ... 2000.0 mVAccuracy:±0.1 (-500.0 ... 500.0 mV), ±0.2 (-2000.0 ... 2000.0 mV)Resolution:1 / 0.1 mVIon concentration:0.00000 ... 999999 % mmol/l, % mol/l, % mg/l, % ppm 0.000 ... 100.000 mmol/l, mol/l, mg/l, ppmCalibration points:1 ... 5Temperature range:-30 ... 130 °CAccuracy:±0.1 (0 ... 100 °C)Resolution:0.1 °CIP code:IP54

Professional pH and redox meter for mobile measurements. The pH/Cond 3320 has a robust, waterproof housing (IP67) and is equipped with a memory as well as a data logger with an adjustable interval between 1 s and 60 min. All entries contain GLP-supporting data, like the date, time and ID number. The modern, waterproof USB interface is used for easy and quick data transfers. Applications: Process chemistry, Life Science, food and beverage industry, pharmaceutical industry (measurement of pH and conductivity according to pharmacopeia).Two inputs for the simultaneous measurement of pH/mV/ISE/redox potentail and conductivityBacklit graphic display for the parallel display of the measured valuesPerfect for monitoring process applicationsWaterproof USB interfaceScope of supply: Meter in transport case, manual, CD-ROM, driver software for USB, batteries, cableSpecificationsMeasuring range / ResolutionpH:-2.000 … 19.999 ± 0.005 pHmV:-2500 ... +2500 ± 1 mVISE (mg/l, µmol/l, mg/kg, ppm, %):0.000 … 999999Conductivity:0.000 µS/cm ... 1000 mS/cmSalinity:0.0 ... 70.0TDS:0 mg ... 199.9 g/lTemp.:-5.0 … 105.0 °C ± 0.1 °CMemory:Manually 200/5000 automaticallyPower supply:4 x 1.5 V AA or 4 x 1.2 V NiMH batteryIP code:IP 67

Professional digital multiparameter meters for mobile measurement, wireless preparation, data logger manually or automatically (timed). Easy to clean with a soft brush under water jet. The Multi 3630 IDS with three universal measurement channels is suitable for all WTW IDS pH, ORP, dissolved oxygen sensors, conductivity cells and turbidity sensors, whether connected to cable or wireless. Documentation of meter and sensor data. User control over MultiLab® users. With USB-A and Mini USB-B interface and colour display.Scope of supply: Meter in a large carrying case with IDS sensors (digital pH sensor SenTix® 940-3, optical sensor FDO® 925-3, digital conductivity cell TetraCon® 925-3), QSC Kit, buffers 4 and 7, conductivity standard, stand, beaker, CD-ROM, batteries, cables, power supply, arming SM Pro

Meter kits are suitable for measuring the pH value and ion concentration of samples and can be used in a wide range of laboratory areas.pH / ion meter SD50 with large 7" touch screen and 5 point calibrationpH electrode InLab® Expert Pro-ISM with robust PEEK shaft, integrated NTC 30 kΩ temperature sensor and ARGENTAL™ reference system. The electrode is always ready for use as the solid XEROLYT® reference electrolyte does not need to be refilledScope of supply: pH / ion meter SevenDirect™ SD50, electrode arm EasyPlace™, pH electrode InLab® Expert Pro-ISM, 3 x 2 calibration buffer sachets pH 4.01, 7.00 and 9.21 or 10.01, protective cover, power supply, get-started-guide

Professional digital multiparameter meters for mobile measurement, wireless preparation, data logger manually or automatically (timed). Easy to clean with a soft brush under water jet. The Multi 3630 IDS with three universal measurement channels is suitable for all WTW IDS pH, ORP, dissolved oxygen sensors, conductivity cells and turbidity sensors, whether connected to cable or wireless. Documentation of meter and sensor data. User control over MultiLab® users. With USB-A and Mini USB-B interface and colour display.Also for controlling OxiTop® IDS.Scope of supply: Instrument, short manual, CD-ROM, rechargeable batteries, driver software for USB, cable, power supply, protection SM Pro, IDS WLM-M module

Versatile multi-parameter meter for measuring pH, conductivity and temperature. Waterproof, with user-replaceable sensor. Suitable for general and industrial purposes, e.g. in the chemical industry and food processing, pools, aquariums and cooling towers.Multi-sensor for pH, conductivity and temperatureSimply toggle the parametersUp to 5 calibration points for pH and 3 calibration points for conductivityWater- and dustproof housingBig LCD DisplayAuto-OffSpecificationspH range: Resolution: Accuracy:0.0 … 14.0 0.1 pH 0.1 pHmV range: Resolution: Accuracy:0 … 1999 µS/cm / 2.00 … 20.00 mS/cm 1 µS/cm / 0.01 mS/cm ±1 % (full scale)Temperature range: Resolution: Accuracy:0 … 50 °C 0.1 °C 0.5 °CIP code:IP 67Power supply:4 x 1.5 V A76 batteries

Portable pH measuring devices by SI Analytics with Memosens® technology. With Memosens® sensor measurement of pH, conductivity and dissolved oxygen by simple sensor exchangeAutomatic detection of the measuring parameter with Memosens® sensorsAutomatic compensation of the ambient pressure for oxygen measurementStorage of up to 10000 data pointsMicro-USB connection to communicate with the HandyLab Pilot software for evaluation of data from digital Memosens® sensors. HandyLab Pilot software (included with delivery), allows for easy management and evaluation of stored data and can be used for device configurationContrast-rich and scratch-resistant clear glass displayDisplay of the sensor status at one glance with SensofaceCalibration of up to 3 points with automatic buffer detectionManual calibration by indicating random buffer valuesReal-time clock and display of battery charging statusExtended operating time of more than 1000 hours with standard batteries (4 x AA) or Li-Ion accumulatorsScope of supply: Set pH-Meter HandyLab 780 incl. AquaLine 90pH, SKK K1A, DIN buffer solutions in ampoules

Professional digital multiparameter meters for mobile measurement, wireless preparation, data logger manually or automatically (timed). Easy to clean with a soft brush under water jet. Sequential multi-parameter measurement. All WTW IDS pH, ORP, dissolved oxygen sensors, conductivity cells and turbidity sensors can be connected to the universal channel, either with cable or wireless module. Data transfer to PC with MultiLab® Importer. With Mini USB-B interface and black/white display.Scope of supply: Meter in a carrying case with buffer 4 and 7, 0.01 mol/l KCl conductivity standard, batteries, USB cable, arming SM Pro

For SevenExcellence™, SevenCompact™, SevenEasy™.

The world's only portable device for liquid analysis with ATEX approval for measurements up to Zone 0/1. Ideal for applications in the process industry. For the first time, Portavo enables direct on-site testing of process measuring points. It is compatible with almost all analog and Memosens process sensors. Memosens sensors with different parameters can be checked without changing the sensor cable.The new MemoLog function allows the user to log calibration data from various Memosens measuring points, which can then be easily transferred to a computer via the standard USB connection. The Paraly SW 112 software enables user-friendly management of all recorded dataA sensor quiver protects the sensor from damage and drying outThe high-performance polymer housing ensures low water absorption and high impact resistanceOver 1000 hours of measurement with a single set of batteries (4 x AA)Data logger with 5000 valuesThe mineral glass display is perfectly readable even after yearsThe world's only portable device for liquid analysis in hazardous locationsSpecificationspH/mV input (analogue): pH: mV: -2 to 16 (0.01) -1300 to 1300 (1% meas. val.,0.3mV/K)Temperature input: Temperature with NTC 30 kO: Temperature with Pt 1000: -20 to +120°C (0.2K) -40 to +250°C (0.2K)Memosens input (ISFET): pH: mV: Temperature range: -2.000 to +16.000 (0.01) -2000 to +2000 (1% meas. val.,0.3mV/K) -50 to +250°C (0,2K)Memosens input, Redox: mV: Temperature range: -2000 to +2000 (1% meas. val.,0.3mV/K) -50 to +250 °C (0.2K)Conductivity measuring range:0.001µS/cm (c0.05cm-1) 0.01µS/cm (c=0.05 to 0.2cm-1) 0.1µS/cm (c0.2cm-1)TDS: Salinity: Resistivity: Concentration:0 to 1999mg/l 0.0 to 45.0g/kg 00.00 to 99.99MO x cm 0.00 to 9.99 (w/w) %Conductivity input, Memosens: Measuring range Sensor SE 215 MS: 10µS/cm to 20mS/cmConductivity input: Temperature compensation: nLF: Linear 0 to 20%/K, ref. temp. adjustable 0 to 120 °CMemosens input, oxygen (optical): Saturation: Concentration: 0.000 to 1000.0% 000µg/l to 100.00mg/lPartial pressure: Temperature measuring range:0.0 to 2000mbar -20 to+150°CPower supply: IP code acc. to DIN EN 60529:4 x AA IP66/67 with pressure compensation

The only portable device for all Memosens parameters. Also for conventional analog sensors. The powerful Li-ion battery can be charged in the device via USB. The clear network diagram provides an at-a-glance view of the sensor condition.The following logging types can be selected:Manual loggingTime-controlled logging at a fixed intervalSignal-controlled logging of measured value and temperatureCombined time and signal-controlled loggingThreshold-controlled logging with pre-triggerThe data logger for up to 10,000 entries records point of measurement, annotation, sensor ID, sensor serial number (Memosens), primary value, temperature, time stamp, and device status.User-friendly softwarePortavo 907 proves that a high level of functionality and easy use are not mutually exclusive. It proceeds step by step through the calibration procedure. Technical terms are clearly explained in the context-sensitive help.High-resolution color graphic displayTransflective and sunlight readableLi-ion batteryMicro USB port and Paraly SW 112 softwareA sensor quiver protects the sensor from damage and drying outThe high-performance polymer housing ensures low water absorption and high impact resistanceIntelligent data logger with 10,000 entries and graphical representationMemosens sensors and analog pH sensors can be used on one device (e.g. flat-membrane sensors)The mineral glass display is perfectly readable even after yearsSpecificationspH/mV input (analogue): pH: mV: -2 to 16 (0.01) -1300 to 1300 (1% meas. val.,0.3mV/K)Temperature input: Temperature with NTC 30 kO: Temperature with Pt 1000: -20 to +120°C (0.2K) -40 to +250°C (0.2K)Memosens input (ISFET): pH: mV: Temperature range: -2.000 to +16.000 (0.01) -2000 to +2000 (1% meas. val.,0.3mV/K) -50 to +250°C (0,2K)Memosens input, Redox: mV: Temperature range: -2000 to +2000 (1% meas. val.,0.3mV/K) -50 to +250 °C (0.2K)Conductivity measuring range:0.001µS/cm (c0.05cm-1) 0.01µS/cm (c=0.05 to 0.2cm-1) 0.1µS/cm (c0.2cm-1)TDS: Salinity: Resistivity: Concentration:0 to 1999mg/l 0.0 to 45.0g/kg 00.00 to 99.99MO x cm 0.00 to 9.99 (w/w) %Conductivity input (analogue): Measuring range withSensor SE 202: Sensor SE 204: 2-electrode sensors: 4-electrode sensors:0.01 to 200µS/cm 1µS/cm to 500mS/cm 0.1µS x c to 200mS x c 0.1µS x c to 1000mS x cTemperature input: Measuring range with NTC 30 kO: Measuring range with Pt 1000: -20 to +120°C -40 to +250°CConductivity input, Memosens: Measuring range Sensor SE 215 MS: 10µS/cm to 20mS/cmConductivity input: Temperature compensation: nLF: Linear 0 to 20%/K, ref. temp. adjustable 0 to 120 °CMemosens input, oxygen (optical): Saturation: Concentration: 0.000 to 1000.0% 000µg/l to 100.00mg/lPartial pressure: Temperature measuring range:0.0 to 2000mbar -20 to+150°CPower supply: IP code acc. to DIN EN 60529:4 x AA IP66/67 with pressure compensation
