Orbital shaker Endeavor™ 5000
Product number:
4693839
Manufacturer:
Ohaus GmbH
Packaging information:
Weight:
9.5 kg
Description
Robust orbital shaker with microprocessor control for a variety of shaking applications of small to medium sized vessels (up to 1 l) in the laboratory. The orbital shaker is equipped with a menu to set, store, and recall multi-step programs.
- Bright, backlit LCD display for speed and time
- RS232 interface for data logging and control
- Visual and audible alarm
- With timer
- Integrated overload and unbalance detection
- Maintenance-free, brushless DC motor
- Suitable for use in cold rooms and incubators
- Small footprint saves space on the lab bench
- Individually customizable with flask clamps or tube racks (please order separately)
Properties
| Amperage: | 1.25 A |
|---|---|
| Depth: | 420 mm |
| Depth moving table: | 300 mm |
| Dimensions (WxDxH): | 262 x 420 x 119 mm |
| Display: | Digital |
| Height: | 119 mm |
| IP code: | IP 21 |
| Manufacturer Article Number: | 30770915 |
| Max. loading capacity: | 4 kg |
| Max. permitted ambient temperature: | 40 °C |
| Max. relative humidity rate: | 80 % |
| Max. speed: | 800 1/min |
| Max. voltage: | 24 V·DC |
| Min. permitted ambient temperature: | -10 °C |
| Min. speed: | 100 1/min |
| Moving table (WxD): | 222 x 300 mm |
| Permitted ambient temperature: | -10 ... 40 °C |
| Plug type: | EU |
| Power supply: | 24 V·DC, 1.25 A |
| Shaking stroke: | 3 mm |
| Speed: | 100 ... 800 1/min |
| Type: | E51LD0403 |
| Type of movement: | Orbital |
| UNSPSC: | 41103811 |
| Weight: | 7.5 kg |
| Width: | 262 mm |
| Width moving table: | 222 mm |
| With timer: | Yes |
Skip product gallery
From
€175.00*
From
€41.70*
From
€206.00*
From
€33.10*
Accessories
Ohaus GmbH
Ohaus GmbH
Tube racks, half size, stationary
Made of PVC coated steel. Incl. screws for easy attachment to platforms.
Ohaus GmbH
Ohaus GmbH
Erlenmeyer Flask Clamps, PVC
Constructed of one piece, molded PVC. Autoclavable. Will not scratch or mark flask like other clamps. Incl. screws for easy attachment to universal platforms. Ideal for polycarbonate flasks.
Ohaus GmbH
Ohaus GmbH
Universal platform
Clamps and racks can be attached to the universal platform for safe shaking of flasks and test tubes.Please order flask clamps and racks separately.
Ohaus GmbH
Ohaus GmbH
Flask Clamps, stainless steel
Clamps for Erlenmeyer flasks, Media bottles* and Fernbach flasks**. Incl. screws for easy attachment to platforms. Clamps for flasks with 50 ml and higher are supplied with a spring to hold the flask in place.
