Overhead stirrer RW 47 digital
Product number:
9816633
Manufacturer:
IKA-Werke GmbH & Co.KG
Packaging information:
Weight:
18.3 kg
Description
Universal laboratory stirrer designed for simple stirring tasks for quantities up to 200 l (H2O). It automatically adjusts the speed through microprocessor controlled technology within the speed range of 57 to 1300 rpm. Safety circuits installed ensures automatic cut-off in an anti-stall or overload conditions. Continuous comparison of shaft speed to desired speed is maintained and variations are adjusted automatically. This guarantees a constant speed even with changes in viscosities of the sample.
- Digital speed display
- Infinitely adjustable speed
- Speed range I (at 50 Hz): 57 to 275 rpm
- Speed range II (at 50 Hz): 275 to 1300 rpm
- Push-through agitator shafts
- Overload protection
- Short-term overload operation
- Slim casing
- Quiet operation
- Error code display
Properties
| Clamping range: | 3 ... 16 mm |
|---|---|
| Depth: | 358 mm |
| Dimensions (WxDxH): | 145 x 358 x 465 mm |
| Display: | Digital |
| Height: | 465 mm |
| IP code: | IP 54 |
| Manufacturer Article Number: | 0004050000 |
| Max. Viscosity: | 100000 mPa·s |
| Max. clamping width: | 16 mm |
| Max. speed: | 1300 1/min |
| Max. stirring capacity: | 200 l |
| Max. torque: | 3000 Ncm |
| Max. voltage: | 400 V |
| Min. clamping width: | 3 mm |
| Min. speed: | 57 1/min |
| Power supply: | 400 V, 50 Hz |
| Power supply frequency: | 50 Hz |
| Rated capacity: | 513 W |
| Speed: | 57 ... 1,300 1/min |
| Type: | RW 47 digital |
| Type of auxiliary energy: | Mains connection |
| Width: | 145 mm |
| With timer: | No |
Skip product gallery
From
€144.00*
From
€355.00*
Accessories
IKA-Werke GmbH & Co.KG
IKA-Werke GmbH & Co.KG
IKA-Werke GmbH & Co.KG
Bosshead R 270 for overhead stirrers
Claming range stand 25 to 36 mmClaming range extension arm 5 to 21 mm
IKA-Werke GmbH & Co.KG
IKA-Werke GmbH & Co.KG
Strap clamps RH 3 for overhead stirrers and Dispersers T 18 and T 25
For vessel Ø 40 to 300 mm.
Skip product gallery
Overhead Stirrers Hei-TORQUE Core
From
€1,081.00*
Bossheads R 182 for overhead stirrers and Dispersers T 18 and T 25
From
€110.00*
Bosshead R 270 for overhead stirrers
From
€144.00*
Bosshead R 271 for overhead stirrers and Disperser T 50 digital ULTRA-TURRAX®
From
€233.00*
Overhead stirrer EUROSTAR 40 digital
From
€1,441.00*
Overhead stirrer EUROSTAR 20 digital
From
€1,246.00*
Overhead stirrer DLS
From
€935.00*
H-stand R 2722 for overhead stirrers and Disperser T 50 digital ULTRA-TURRAX®
From
€834.00*
Overhead stirrer EUROSTAR 60 control
From
€2,647.00*
Strap clamps RH 5 for overhead stirrers an Disperser T 50 digital ULTRA-TURRAX®
From
€437.00*
Similar products
Compact, electronic overhead stirrer for easy operation.Can be integrated in closed systems such as fume hoods, reactors or production systemsSuitable for low to medium viscosity mediaQuick-action chuck for stirring tools up to 10 mm diameter"Max" button for short-term operation at maximum speedTimer functionDigital rotation speed displayAutomatic switch-off with overheating protection
Claming range stand/extension arm 6 to 16 mm.
Claming range stand 25 to 36 mmClaming range extension arm 5 to 21 mm
Claming range stand 34 mmClaming range extension arm 16 mm
Universal laboratory stirrer designed for simple stirring tasks for quantities up to 25l (H2O). It automatically adjusts the speed through microprocessor controlled technology within the speed range of 0/30 to 2000rpm. Safety circuits installed ensures automatic cut-off in an anti-stall or overload conditions. Continuous comparison of shaft speed to desired speed is maintained and variations are adjusted automatically. This guarantees a constant speed even with changes in viscosities of the sample.Digital speed displayInfinitely adjustable speedPush-through agitator shaftsOverload protectionShort-term overload operation
Overhead stirrer designed for simple stirring tasks for quantities up to 15 l (H2O). It automatically adjusts the speed through microprocessor controlled technology within the speed range of 0/30 to 2000 rpm. Safety circuits installed ensures automatic cut-off in an anti-stall or overload conditions. Continuous comparison of shaft speed to desired speed is maintained and variations are adjusted automatically. This guarantees a constant speed even with changes in viscosities of the sample.Digital speed displayInfinitely adjustable speedPush-through agitator shaftsOverload protectionShort-term overload operation
Powerful overhead stirrer with display for stirring of low to medium viscosity media up to 25000 mPas.Stable torque over the entire speed range with automatic compensation on viscosity changesElectronic speed controlGentle start-up to avoid splashing and blisteringChemical resistant and corrosion protected housingBlocking detection with switch-off functionNo tool required for assembly of the stirring toolDisplay shows all important parametersTimer with automatic power-off (up to 999 min 59 sec)Scope of supply: Overhead stirrer
Stable stands with H-shaped base. Stands have a levelling screw to compensate for unevenness on the laboratory bench. Max. load 10 kg.
