Material test chamber FP series
Product number:
9883710
Manufacturer:
BINDER GmbH
Packaging information:
Weight:
57 kg
Description
The material test chambers with mechanical convection reliably ensure short drying times and fast heating. Thanks to programme functions and adjustable fan, temperature and recirculation conditions can be individually controlled even over a longer period of time.
- High temperature accuracy due to APT.line™ technology
- Adjustable fan speed
- Controller with interval and real-time programming
- User-friendly controller with large display
- Electromechanical control of the exhaust air flap
- Class 2 independent adjustable temperature safety device (DIN 12880) and class 3.1 independent temperature safety device (DIN 12880) with visual/acoustic alarm selectable on controller
- Models up to 115 l stackable
- Ergonomic handle design
- Computer interface: Ethernet
- Internal data logger, measured values can be read out in open format via USB
Properties
| Depth int.: | 342 mm |
|---|---|
| Ext. depth: | 596 mm |
| Ext. height: | 622 mm |
| Ext. width: | 560 mm |
| External dimensions (WxDxH): | 560 x 596 x 622 mm |
| Height int.: | 440 mm |
| Int. width: | 400 mm |
| Internal dimensions (WxDxH): | 400 x 342 x 440 mm |
| Manufacturer Article Number: | 9010-0363 |
| Max. no. of inserts: | 4 |
| Max. temperature: | 300 °C |
| Max. voltage: | 230 V |
| Min. temperature: | +10 °C |
| Nominal capacity: | 60 l |
| Power supply: | 230 V, 50/60 Hz |
| Power supply frequency: | 50/60 Hz |
| Rated capacity: | 1200 W |
| Temperature: | RT+10 ... 300 °C |
| Temperature addition: | RT |
| Temperature stability: | ±0,4 K (150 °C) |
| Type: | FP 56 |
| Type of auxiliary energy: | Mains connection |
| UNSPSC: | 41104510 |
| Weight: | 41 kg |
