Tempering liquids for high temperature circulators Forte HT

DURAN®. For heating and cooling liquids. Thermostatting liquid is circulating between the double walls of the beaker jacket. With glass olives (O.D. 12mm) for thermostat hoses. Coolant ram pressure: 0.5bar at maximum, operating temperature: +300°C at maximum. Special sizes available on request.

Bath liquids.Use of the appropriate liquids for heat transfer listed here offers many advantages:Safe to use, non toxic, and generally odourless formulationsResistance to ageing and viscosity changes with low susceptibility to corrosion.Silicone oils (SIL).Non-flammable, with long operational life.Synthetic heat transfer fluids (Synth).Usually formulated from a hydrocarbon base with low viscosity within the recommended working temperature range.Viscosity.For optimal temperature stability the bath fluid must be of low viscosity.Fire point.Fluids can spontaneously ignite above a certain temperature. EN 61010 stipulates that the maximum working temperature of the liquid should be 25 °C below its' fire point.Heating up range.Prolonged use is not permitted as the self-heating effect within these liquids may cause the overtemperature protection system of the pump unit to operate and shut down the pump.Operating temperature range.Thermostats may only be operated for an extended time in this range under certain conditions. Viscosity must not exceed 30 mPas. Otherwise pumps will not achieve their stated performance figures.Working temperature range.The long-term use range for peak thermostatic bath performance. Maximum viscosity level is approx. 5 mPas.

Temperature hoses with special triple insulation and two M16 x 1 connections. The ends are covered with silicone caps for protection. Max. pressure 6 bar (at 20 °C), 4 bar (at 350 °C).

Huber thermal fluids are recommended because they have the best possible thermodynamic and environmental characteristics. Safe reliable operation relies on compliance with safety standards to ensure optimal results.Temperature ranges refer to use in closed systems.

Long-term tested for safe and reliable operation. Low toxicityLow viscosityHigh stabilityAlmost odor-freeGood thermal conductivityLow corrosion susceptibilityWide temperature ranges

Long-term tested for safe and reliable operation.Low toxicityLow viscosityHigh stabilityAlmost odor-freeGood thermal conductivityLow corrosion susceptibilityWide temperature ranges

Prevents premature rusting and the growth of algae. Ideal for use in circulators, water baths, shaking water baths or heating baths. For routine applications from 5 to 90 °C.

E-grade - innovative activation keys for the functionality to suit your budget and process requirementsEvery application requires particular functions. If the circulator is to be used in a range of applications it will generally require greater functionality. The required functionality grows with the complexity of the application. The innovative "E-grade" has the answer. Models with the Pilot ONE Controller have a comprehensive range of functions suited to the classical temperature control applications. The E-grade allows the functionality to be extended at any time to suit new process requirements and budget. E-grade stands for electronic upgrade and it is simple to do: To extend the functionality a unit specific code is entered via the controller. This code is specific to the serial number of the unit and is either already entered at the factory for new units or it can be activated at a later date. The code is sent by email. There is no requirement for a hardware or software update.The E-grade "Explore" for Unistats is more than just another functions package. It makes important information available to users of Unistat temperature control systems. Temperature values and temperature differentials as well as for the actual heating power, cooling power and pump power within the system are displayed on the touch-panel. E-grade "Explore" is an evolution of the existing Unistat technology. Existing sensors are utilised to make important process temperature and power data visible. In addition to making the data visible on the display of the device, it can also be accessed via the digital interfaces for further processing. Application examples for E-grade® "Explore": Process and product development and optimisation Use-Tests of raw materials, quality control Enhanced data collection for scale-up trials

Stabilising agent for water baths, thermostats etc.Should be prepared with distilled water if possible.Attention: Toxic to aquatic organisms with long-term effects. Avoid release into the environment.

For external thermoregulation applications, standard cable length 1.5 m
